Spouted Pouch Filler & Capper RS-2

The Spouted Pouch Filler & Capper RS-2 machine can process two premade pouches at once based on a two-filler configuration. This machine can pack viscous and free-flowing liquids, even those containing particulates. Ideal for various liquid fill applications such as edible oils, sauces, drinks, and more. Non-edible applications examples are synthetic oils, liquid soaps, paint, shampoo, lotions, liquid detergents, and more. Easy integration with piston fillers makes this machine a top choice for a complete single-liquid packaging solution.

To download the brochure or to receive the floor plans for the Spouted Pouch Filler & Capper RS-2, visit the ‘More Resources’ section below.

spout pouch filling and capping machine RS-2
40
pouches per
minute max.
100mL
min. fill
volume
2L
max. fill
volume

Equipment specifications are subject to change without notice. Check with our team for specifications based on your application.

Product Type

Liquid Icon White

Liquid

Parts + Services

We also proudly offer non-proprietary off the shelf parts for all of our machines and a wide variety of pre- and post- delivery services to all of our customers.

Spouted Pouch Filler & Capper RS-2

MACHINE
FEATURES

Bag style possibilities with this machine. Click on a desired bag style to learn more.

The Spouted Pouch Filler & Capper RS-2 boasts a range of features designed for efficiency, ease of use, and reliable performance:

  • Up to 20 cycles/minute/filling head, total of 2 fillers.
  • Possible speeds of up to 40 pouches/minute
  • Easy tooling changeover for various sizes of pouches
  • Easy pouch magazine load on an indexing conveyor
  • Heavy-duty rotary indexer for precise placement of pouches on every cycle
  • Automatic pick and placement of pouches in the rotary table
  • Automatic discard of empty pouch magazine
  • Set of 2 ink jet print heads for ‘best before’ date printing
  • Set of 2 independent capping heads with torque out capability
  • Stainless Steel Eject Chutes for easy pouch collection
  • Stainless Steel overall construction with continuous weld
  • 10” enclosed HMI with easy menu interface for various operations
  • (Omron / Allen Bradley) Motion Controller PLC for synchronous and smooth motion
  • Click-to-order non-proprietary parts
  • Set of 2 filling piston pumps with easy volume adjustments
  • Servo-controlled filling station built with single axis robotics
  • Pouch detection ‘No Pouch - No Fill’ capability

Enhance the functionality of your Spouted Pouch Filler & Capper RS-2 with these optional features:

  • Take away conveyor
  • Free flowing piston fillers​
  • Viscous Piston filler​
  • Gas flush

Ensure seamless integration into your production line with the Spouted Pouch Filler & Capper RS-2's technical specifications:

Standard technical data: Spouted Pouch Filler & Capper RS-2
No of fillers: 2
Machine height: 72”
Machine width: 180”
Machine length: 120”
Electronic Control: Omron PLC (Allen Bradley optional)
Electrical power supply: 230-volt, Single Phase, 60 Hz, 30 Amp
Human machine interface (HMI): 10" Color Touch Screen
Compressed air pressure: 90 psi
Power consumption: 6 KW
Fill Range: 100 ml to 2000 ml
Pouch Width Range: 3.15 Inches (80mm) - 6.5 Inches (165mm)
Pouch Length: 5.12 Inches (130mm) – 10 Inches (254mm)

check weigher (2)

Check Weighers

outfeed conveyor (1)

Infeed / Outfeed Conveyors

PLATFORM MEZZANINE

Mezzanine / Platforms

MULTILANE PISTON FILLER

Multilane Piston Filler

in line printer (2)

Printers

transfer pump

Product Transfer Pumps

Bag Styles

Bag style possibilities with this machine. Click on a desired bag style to learn more.

The Spouted Pouch Filler & Capper RS-2 boasts a range of features designed for efficiency, ease of use, and reliable performance:

  • Up to 20 cycles/minute/filling head, total of 2 fillers.
  • Possible speeds of up to 40 pouches/minute
  • Easy tooling changeover for various sizes of pouches
  • Easy pouch magazine load on an indexing conveyor
  • Heavy-duty rotary indexer for precise placement of pouches on every cycle
  • Automatic pick and placement of pouches in the rotary table
  • Automatic discard of empty pouch magazine
  • Set of 2 ink jet print heads for ‘best before’ date printing
  • Set of 2 independent capping heads with torque out capability
  • Stainless Steel Eject Chutes for easy pouch collection
  • Stainless Steel overall construction with continuous weld
  • 10” enclosed HMI with easy menu interface for various operations
  • (Omron / Allen Bradley) Motion Controller PLC for synchronous and smooth motion
  • Click-to-order non-proprietary parts
  • Set of 2 filling piston pumps with easy volume adjustments
  • Servo-controlled filling station built with single axis robotics
  • Pouch detection ‘No Pouch - No Fill’ capability

Enhance the functionality of your Spouted Pouch Filler & Capper RS-2 with these optional features:

  • Take away conveyor
  • Free flowing piston fillers​
  • Viscous Piston filler​
  • Gas flush

Ensure seamless integration into your production line with the Spouted Pouch Filler & Capper RS-2's technical specifications:

Standard technical data: Spouted Pouch Filler & Capper RS-2
No of fillers: 2
Machine height: 72”
Machine width: 180”
Machine length: 120”
Electronic Control: Omron PLC (Allen Bradley optional)
Electrical power supply: 230-volt, Single Phase, 60 Hz, 30 Amp
Human machine interface (HMI): 10" Color Touch Screen
Compressed air pressure: 90 psi
Power consumption: 6 KW
Fill Range: 100 ml to 2000 ml
Pouch Width Range: 3.15 Inches (80mm) - 6.5 Inches (165mm)
Pouch Length: 5.12 Inches (130mm) – 10 Inches (254mm)

check weigher (2)

Check Weighers

outfeed conveyor (1)

Infeed / Outfeed Conveyors

PLATFORM MEZZANINE

Mezzanine / Platforms

MULTILANE PISTON FILLER

Multilane Piston Filler

in line printer (2)

Printers

transfer pump

Product Transfer Pumps
